The New Dometic CCF-T Center Console Refrigerator easily integrates into the center console of your supported vehicle. When friends first see the soft touch finish and perfect fit they will think it was factory installed. This refrigerator offers you the ability to carry along food, drinks and even life saving medication without having a large bulky refrigerator in the vehicle cab.
This unit is built tough on Dometic portable compressor technology with your personal freedom in mind. The total holding capacity is 12 x 12oz cans. This refrigerator was designed to work with your 2015 to 2020 Ford pickup as well as 2018 and Newer Ford Expedition.
Dometic has pulled no punches when designing this great new product. With generous insulation and robust features such as low energy operation and a low noise automotive approved compressor you just can't go wrong when upgrading your Ford pickup or Expedition with the innovative CCF-T.
You will feel good knowing you have cold drinks in the cab and that your battery is in good condition. This unit draws just over 5 amps on start up and around 4 amps during normal operation. If the refrigerator is left on while the vehicle is turned off the refrigerator will automatically shut off when it detects the battery voltage is dropping too low. This not only protects your battery, but also ensures your engine will crank over when you turn the key!
Installing your new refrigerator could only be easier if Dometic did the job for you. Doing the work yourself should take less than 45 minutes. A template and instructions are included for the placement of the required ventilation hole. This hole should be cut using a portable or power drill and small hole cutting adapter (hole saw). Once the dust is cleaned up just place a few pieces of insulation padding, plug the refrigerator into your power outlet then ease the unit into the center console. Job complete.
Features
- Low Noise Compressor Design
- Low Noise Fan Design
- On/Off Button with LED Indicator
- Interior LED
- Shock Absorbing Rubber Feet
- Two 5V USB Power Outlets
- Warranty: Limited One-Year Warranty
What's In The Box
- 1 x Refrigerator Unit
- 1 x 12V Accessory Type Plug
- 1 x Rubber Mat
- 1 x Top Closeout Tray
- 1 x Front Fan with Housing
- 1 x Front Fan Template
- 1 x Foam Console Wall Spacer (padding/insulation)
| Specifications |
| Power Supply | 12 Volts DC |
| Operating Voltage | 12V DC to 16V DC |
| Low Voltage Cut-out | 12V |
| Power Output | USB 5V x 2 |
| Power Startup Consumption | 5.6A |
| Power Operation Consumption | 4.5A |
| Storage Capacity | Either 12 - 12oz Cans, or 6 - 20oz bottles |
| Dimensions | H 13" x W 12" x D 16" (H = top to bottom, W = side to side, D = back to front) |
| Weight | 14.3 lbs |
| Thermostat Control | NO - NONE |
| Internal Operating Temp Range | 32°F - 41°F, 0°C - 5°C |
| Vehicle Fit Guide | Ford F-150 (2015-2020)
Ford F-250 (2015-2020)
Ford F-350 (2015-2020)
Ford Expedition (2018 and newer) |
